Personal Design Portfolio

Industrial designs and projects Prototypes

Industrial designs and projects

Composite Pellets machine

Machine for producing organical composites.

V mixer

Machine for the combination of elements.

Horizontal conveyor

Machine for the transportation of food with specif characteristics.

Feed hopper with magnetic vibrator

Machine used for transportation of snacks in the food industry.

Fastback transporter

Machine used for transporting a specific type of food.

Automated transportation line

Project used as a transportation line of bottles with specific dimensions.

Automated Material Driving Structure

Hidraulic project for the transportation of bottles in six packs.

Water wave generator machine

The following project is one of the most recent collaborations. The project's aim as its name suggest is the generation of water waves for recreational purposes in an amusement park in Ecuador.

The project is a mechanical design of a machine with enougth power to move water and generate a wave for recreational purposes. It has a lot of physical considerations, previous knowledge and mathematical develop. The image of the project is from an early prototype and due to owner patent rigths can not be shown the actual shape of the machine.
